NSE4_FGT-7.2 Online Practice Questions and Answers

Which two statements are correct about SLA targets? (Choose two.)

A. You can configure only two SLA targets per one Performance SLA.

B. SLA targets are optional.

C. SLA targets are required for SD-WAN rules with a Best Quality strategy.

D. SLA targets are used only when referenced by an SD-WAN rule.

Which two statements are correct about a software switch on FortiGate? (Choose two.)

A. It can be configured only when FortiGate is operating in NAT mode

B. Can act as a Layer 2 switch as well as a Layer 3 router

C. All interfaces in the software switch share the same IP address

D. It can group only physical interfaces

The IPS engine is used by which three security features? (Choose three.)

A. Antivirus in flow-based inspection

B. Web filter in flow-based inspection

C. Application control

D. DNS filter

E. Web application firewall

Refer to the exhibits.

The exhibits show the firewall policies and the objects used in the firewall policies.

The administrator is using the Policy Lookup feature and has entered the search criteria shown in the exhibit.

Which policy will be highlighted, based on the input criteria?

A. Policy with ID 4.

B. Policy with ID 5.

C. Policies with ID 2 and 3.

D. Policy with ID 4.

Refer to the exhibits.

Exhibit A shows a network diagram. Exhibit B shows the firewall policy configuration and a VIP object configuration.

The WAN (port1) interface has the IP address 10.200.1.1/24.

The LAN (port3) interface has the IP address 10.0.1.254/24.

If the host 10.200.3.1 sends a TCP SYN packet on port 10443 to 10.200.1.10, what will the source address, destination address, and destination port of the packet be, after FortiGate forwards the packet to the destination?

A. 10.0.1.254, 10.0.1.10, and 443, respectively

B. 10.0.1.254, 10.200.1.10, and 443, respectively

C. 10.200.3.1, 10.0.1.10, and 443, respectively

D. 10.0.1.254, 10.0.1.10, and 10443, respectively

An employee needs to connect to the office through a high-latency internet connection.

Which SSL VPN setting should the administrator adjust to prevent SSL VPN negotiation failure?

A. idle-timeout

B. login-timeout

C. udp-idle-timer

D. session-ttl

Refer to the exhibits.

Exhibit A shows a topology for a FortiGate HA cluster that performs proxy-based inspection on traffic. Exhibit B shows the HA configuration and the partial output of the get system ha status command.

Based on the exhibits, which two statements about the traffic passing through the cluster are true? (Choose two.)

A. For non-load balanced connections, packets forwarded by the cluster to the server contain the virtual MAC address of port2 as source.

B. The traffic sourced from the client and destined to the server is sent to FGT-1.

C. The cluster can load balance ICMP connections to the secondary.

D. For load balanced connections, the primary encapsulates TCP SYN packets before forwarding them to the secondary.

In an explicit proxy setup, where is the authentication method and database configured?

A. Proxy Policy

B. Authentication Rule

C. Firewall Policy

D. Authentication scheme

The exhibit shows the configuration for the SD-WAN member, Performance SLA, and SD-WAN Rule, as well as the output of diagnose sys virtual-wan-link health-check.

Which interface will be selected as an outgoing interface?

A. port2

B. port3

C. port4

D. port1

Refer to the exhibits.

Exhibit A shows a network diagram. Exhibit B shows the central SNAT policy and IP pool configuration.

The WAN (port1) interface has the IP address 10.200.1.1/24.

The LAN (port3) interface has the IP address 10.0.1.254/24.

A firewall policy is configured to allow all destinations from LAN (port3) to WAN (port1).

Central NAT is enabled, so NAT settings from matching central SNAT policies will be applied.

Which IP address will be used to source NAT (SNAT) the traffic, if the user on Local-Client (10.0.1.10) pings the IP address of Remote-FortiGate (10.200.3.1)?

A. 10.200.1.99

B. 10.200.1.1

C. 10.200.1.49

D. 10.200.1.149
