CKS Online Practice Questions and Answers

Correct Answer: A

$ kubectl get ing -n NAME HOSTS ADDRESS PORTS AGE cafe-ingress cafe.com 10.0.2.15 80 25s

$ kubectl describe ing -n Name: cafe-ingress Namespace: default Address: 10.0.2.15 Default backend: default-http-backend:80 (172.17.0.5:8080) Rules: Host Path Backends

cafe.com

/tea tea-svc:80 ()

/coffee coffee-svc:80 ()

Annotations:

kubectl.kubernetes.io/last-applied-configuration:

{"apiVersion":"networking.k8s.io/v1","kind":"Ingress","metadata":{"annotations":{},"name":"c afe-ingress","namespace":"default","selfLink":"/apis/networking/v1/namespaces/default/ingress es/cafe-ingress"},"spec":{"rules":

[{"host":"cafe.com","http":{"paths":[{"backend":{"serviceName":"tea- svc","servicePort":80},"path":"/tea"},{"backend":{"serviceName":"coffee- svc","servicePort":80},"path":"/coffee"}]}}]},"status":{"loadBalancer":{"ingress":

[{"ip":"169.48.142.110"}]}}}

Events:

Type Reason Age From Message

Normal CREATE 1m ingress-nginx-controller Ingress default/cafe-ingress Normal UPDATE 58s ingress-nginx-controller Ingress default/cafe-ingress $ kubectl get pods -n NAME READY STATUS RESTARTS AGE ingress-nginx-controller-67956bf89d-fv58j 1/1 Running 0 1m

$ kubectl logs -n ingress-nginx-controller-67956bf89d-fv58j ---------------------------------------------------------------------------------------------------- NGINX Ingress controller Release: 0.14.0 Build: git-734361d Repository: https://github.com/kubernetes/ingress-nginx

Correct Answer: A

Correct Answer: A

Fix all of the following violations that were found against the API server:

a. Ensure that the RotateKubeletServerCertificate argument is set to true.

apiVersion: v1 kind: Pod metadata: creationTimestamp: null labels: component: kubelet tier: control-plane name: kubelet namespace: kube-system spec: containers:

-command:

-kube-controller-manager + - --feature-gates=RotateKubeletServerCertificate=true image: gcr.io/google_containers/kubelet-amd64:v1.6.0 livenessProbe: failureThreshold: 8 httpGet: host: 127.0.0.1 path: /healthz port: 6443 scheme: HTTPS initialDelaySeconds: 15 timeoutSeconds: 15 name: kubelet resources: requests: cpu: 250m volumeMounts:

-

mountPath: /etc/kubernetes/ name: k8s readOnly: true

-

mountPath: /etc/ssl/certs name: certs

-

mountPath: /etc/pki name: pki hostNetwork: true volumes:

-

hostPath: path: /etc/kubernetes name: k8s

-

hostPath: path: /etc/ssl/certs name: certs

-

hostPath: path: /etc/pki name: pki

b.

Ensure that the admission control plugin PodSecurityPolicy is set.

audit: "/bin/ps -ef | grep $apiserverbin | grep -v grep"

tests:

test_items:

-flag: "--enable-admission-plugins"

compare:

op: has

value: "PodSecurityPolicy"

set: true

remediation: |

Follow the documentation and create Pod Security Policy objects as per your environment.

Then, edit the API server pod specification file $apiserverconf

on the master node and set the --enable-admission-plugins parameter to a

value that includes PodSecurityPolicy :

--enable-admission-plugins=...,PodSecurityPolicy,...

Then restart the API Server.

scored: true

c. Ensure that the --kubelet-certificate-authority argument is set as appropriate. audit: "/bin/ps -ef | grep $apiserverbin | grep -v grep"

tests: test_items:

-flag: "--kubelet-certificate-authority"

set: true

remediation: |

Follow the Kubernetes documentation and setup the TLS connection between the

apiserver and kubelets. Then, edit the API server pod specification file

$apiserverconf on the master node and set the --kubelet-certificate-authority

parameter to the path to the cert file for the certificate authority.

--kubelet-certificate-authority=

scored: true

Fix all of the following violations that were found against the ETCD:

a.

Ensure that the --auto-tls argument is not set to true Edit the etcd pod specification file $etcdconf on the masternode and either remove the -- auto-tls parameter or set it to false.--auto-tls=false

b.

Ensure that the --peer-auto-tls argument is not set to true

Edit the etcd pod specification file $etcdconf on the masternode and either remove the -- peer-auto-tls parameter or set it to false.--peer-auto-tls=false

Correct Answer: A

apiVersion: policy/v1beta1

kind: PodSecurityPolicy

metadata:

name: restricted

annotations:

seccomp.security.alpha.kubernetes.io/allowedProfileNames:

'docker/default,runtime/default'

apparmor.security.beta.kubernetes.io/allowedProfileNames: 'runtime/default' seccomp.security.alpha.kubernetes.io/defaultProfileName: 'runtime/default' apparmor.security.beta.kubernetes.io/defaultProfileName: 'runtime/default' spec:

privileged: false

# Required to prevent escalations to root.

allowPrivilegeEscalation: false

# This is redundant with non-root + disallow privilege escalation, # but we can provide it for defense in depth.

requiredDropCapabilities:

-ALL

# Allow core volume types.

volumes:

-'configMap'

-'emptyDir'

-'projected'

-'secret'

-'downwardAPI'

# Assume that persistentVolumes set up by the cluster admin are safe to use.

-'persistentVolumeClaim'

hostNetwork: false

hostIPC: false

hostPID: false

runAsUser:

# Require the container to run without root privileges.

rule: 'MustRunAsNonRoot'

seLinux:

# This policy assumes the nodes are using AppArmor rather than SELinux.

rule: 'RunAsAny'

supplementalGroups:

rule: 'MustRunAs'

ranges:

# Forbid adding the root group.

-

min: 1

max: 65535

fsGroup:

rule: 'MustRunAs'

ranges:

# Forbid adding the root group.

-

min: 1

max: 65535

readOnlyRootFilesystem: false

Correct Answer: A

Correct Answer: A

Correct Answer: A

Correct Answer: A

Create a PSP that will prevent the creation of privileged pods in the namespace. $ cat clusterrole-use-privileged.yaml apiVersion: rbac.authorization.k8s.io/v1

kind: ClusterRole metadata: name: use-privileged-psp rules:

-apiGroups: ['policy']

resources: ['podsecuritypolicies']

verbs: ['use']

resourceNames:

-default-psp

apiVersion: rbac.authorization.k8s.io/v1 kind: RoleBinding metadata: name: privileged-role-bind namespace: psp-test roleRef: apiGroup: rbac.authorization.k8s.io kind: ClusterRole name: use-privileged-psp subjects:

-kind: ServiceAccount name: privileged-sa $ kubectl -n psp-test apply -f clusterrole-use-privileged.yaml

After a few moments, the privileged Pod should be created.

Create a new PodSecurityPolicy named prevent-privileged-policy which prevents the creation of privileged pods.

apiVersion: policy/v1beta1

kind: PodSecurityPolicy

metadata:

name: example

spec:

privileged: false # Don't allow privileged pods!

# The rest fills in some required fields.

seLinux:

rule: RunAsAny

supplementalGroups:

rule: RunAsAny

runAsUser:

rule: RunAsAny

fsGroup:

rule: RunAsAny

volumes:

-'*'

And create it with kubectl:

kubectl-admin create -f example-psp.yaml

Now, as the unprivileged user, try to create a simple pod:

kubectl-user create -f- <

apiVersion: v1

kind: Pod

metadata:

name: pause

spec:

containers:

-name: pause

image: k8s.gcr.io/pause

EOF

The output is similar to this:

Error from server (Forbidden): error when creating "STDIN": pods "pause" is forbidden:

unable to validate against any pod security policy: []

Create a new ServiceAccount named psp-sa in the namespace default.

$ cat clusterrole-use-privileged.yaml

apiVersion: rbac.authorization.k8s.io/v1 kind: ClusterRole metadata: name: use-privileged-psp rules:

-apiGroups: ['policy']

resources: ['podsecuritypolicies']

verbs: ['use']

resourceNames:

-default-psp

apiVersion: rbac.authorization.k8s.io/v1 kind: RoleBinding metadata: name: privileged-role-bind namespace: psp-test roleRef: apiGroup: rbac.authorization.k8s.io kind: ClusterRole name: use-privileged-psp subjects:

-kind: ServiceAccount name: privileged-sa $ kubectl -n psp-test apply -f clusterrole-use-privileged.yaml After a few moments, the privileged Pod should be created.

Create a new ClusterRole named prevent-role, which uses the newly created Pod Security Policy prevent-privileged-policy.

apiVersion: policy/v1beta1

kind: PodSecurityPolicy

metadata:

name: example

spec:

privileged: false # Don't allow privileged pods!

# The rest fills in some required fields.

seLinux:

rule: RunAsAny

supplementalGroups:

rule: RunAsAny

runAsUser:

rule: RunAsAny

fsGroup:

rule: RunAsAny

volumes:

-'*'

And create it with kubectl:

kubectl-admin create -f example-psp.yaml

Now, as the unprivileged user, try to create a simple pod:

kubectl-user create -f- <

apiVersion: v1

kind: Pod

metadata:

name: pause

spec:

containers:

-name: pause

image: k8s.gcr.io/pause

EOF

The output is similar to this:

Error from server (Forbidden): error when creating "STDIN": pods "pause" is forbidden:

unable to validate against any pod security policy: []

Create a new ClusterRoleBinding named prevent-role-binding, which binds the created ClusterRole prevent-role to the created SA psp-sa.

apiVersion: rbac.authorization.k8s.io/v1

# This role binding allows "jane" to read pods in the "default" namespace. # You need to already have a Role named "pod-reader" in that namespace.

kind: RoleBinding

metadata:

name: read-pods

namespace: default

subjects:

# You can specify more than one "subject"

-kind: User name: jane # "name" is case sensitive apiGroup: rbac.authorization.k8s.io roleRef: # "roleRef" specifies the binding to a Role / ClusterRole kind: Role #this must be Role or ClusterRole name: pod-reader # this must match the name of the Role or ClusterRole you wish to bind to apiGroup: rbac.authorization.k8s.io

apiVersion: rbac.authorization.k8s.io/v1 kind: Role metadata: namespace: default name: pod-reader rules:

-apiGroups: [""] # "" indicates the core API group resources: ["pods"] verbs: ["get", "watch", "list"]

Correct Answer: A

1.

apiVersion: node.k8s.io/v1

2.

kind: RuntimeClass

3.

metadata:

4.

name: not-trusted

5.

handler: runsc [desk@cli] $ k apply -f runtime.yaml[desk@cli] $ k get pods

1.

NAME READY STATUS RESTARTS AGE

2.

nginx-6798fc88e8-chp6r 1/1 Running 0 11m

3.

nginx-6798fc88e8-fs53n 1/1 Running 0 11m

4.

nginx-6798fc88e8-ndved 1/1 Running 0 11m [desk@cli] $ k get deploy

1.

NAME READY UP-TO-DATE AVAILABLE AGE

2.

nginx 3/3 11 3 5m [desk@cli] $ k edit deploy nginx

[desk@cli] $vim runtime.yaml

Correct Answer: A

Kubernetes auditing provides a security-relevant chronological set of records about a cluster. Kube-apiserver performs auditing. Each request on each stage of its execution generates an event, which is then pre-processed according to a

certain policy and written to a backend. The policy determines what's recorded and the backends persist the records. You might want to configure the audit log as part of compliance with the CIS (Center for Internet Security) Kubernetes

Benchmark controls.

The audit log can be enabled by default using the following configuration in cluster.yml:

services:

kube-api:

audit_log:

enabled: true

When the audit log is enabled, you should be able to see the default values at /etc/kubernetes/audit-policy.yaml

The log backend writes audit events to a file in JSONlines format. You can configure the log audit backend using the following kube-apiserver flags:

--audit-log-path specifies the log file path that log backend uses to write audit events. Not specifying this flag disables log backend. - means standard out --audit-log-maxage defined the maximum number of days to retain old audit log files

--audit-log-maxbackup defines the maximum number of audit log files to retain

--audit-log-maxsize defines the maximum size in megabytes of the audit log file before it gets rotated

If your cluster's control plane runs the kube-apiserver as a Pod, remember to mount the hostPath to the location of the policy file and log file, so that audit records are persisted.

For example:

--audit-policy-file=/etc/kubernetes/audit-policy.yaml \

--audit-log-path=/var/log/audit.log
