71200X Online Practice Questions and Answers

When adding an H.323 Station, which three fields must be administered? (Choose three.)

A. Extension

B. Port

C. Set Template/Set Type

D. Security Code

E. Class of Service (COS)

Which two are functions of Avaya Aura Session Manager (SM)? (Choose two.)

A. Act as an H.323 call controller.

B. Acts as a registrar to SIP endpoints.

C. Act as an H.323 routing engine.

D. Register digital (DCP) and H.323endpoints.

E. Act as a sophisticated SIP routing engine.

When a simple SIP telephone without CM Features registers to the Avaya Aura Core, which IP address will it register to?

A. Avaya Aura System Manager IP Address

B. Avaya Aura Session Manager Management IP Address

C. Avaya Aura Session Manager SM100 IP Address

D. Avaya Aura Communication Manager IP Address

When you attempt to login to one X?Communicator using TLS, It falls and displays the Login Error: "The security certificate required for login is not installed. Please contact your support team."

What must you do to fix this error?

A. Install the SM Identity certificate into the Trusted Root Certificate Authorities on CM.

B. Install the Certificate Authority certificate that signed Avaya Aura Session Manager's (SM) Identity certificate into the Trusted Root Certificate Authorities on the PC.

C. Import the Identity Certificate from the Security menu of the one-X?Communicator.

D. Export the identity certificate from Avaya Aura Session Manager and Import it into the PC using copy and paste.

A large enterprise is using an Avaya Aura Core. An Avaya SIP Endpoint, one X?Communicator, controlled by Avaya Aura Communication Manager (CM), has been configured with three feature buttons, but none of the buttons appear on the telephone interface. The telephone shows successful registration with Avaya Aura Session Manager (SM) at the SIP Level. What are two possible causes for this feature button failure? (Choose two.)

A. The SM Server is down.

B. The SIP Signaling Group between SM and CM is down.

C. The telephone is pointing to CM Instead of SM for registration.

D. DSP resource has not been reserved specifically for CM features.

E. The Application Sequence for CM has not been selected for that SIP user In SM.

Which product from the Collaboration Applications Bundle provides Avaya Equinox clients with Auto-Configuration options?

A. Avaya Aura Device Services (AADS)

B. Avaya Aura Web Gateway (AAWG)

C. Avaya Breeze?

D. Application Enablement Services (AES)

If you administer an Avaya Aura Communication Manager from the Service Port, what must be the IP

Address of your Laptop?

A. 192.11.13.6

B. 192.11.13.5

C. 255.255.255.252

D. 192.168.11.1

Which three actions can be performed together to save CM translations to CM disk, and make a copy be sent to every survivable server? (Choose three.)

A. Execute sa tr all from SAT.

B. From Avaya Aura System Manager (SMGR) Service>; Backup and Restore.

C. From Avaya Aura System Manager (SMGR) launch Element Cut-Through.

D. From Inventory> Synchronization > Communication System.

E. Execute the Linux sat ransall command.

Which two Virtualization Models are supported by Avaya? (Choose two.)

A. Combined Application model

B. Virtualization Platform Model

C. Solution Module

D. Appliance Model

E. Virtualized Environment Model

Under which circumstance would an Avaya Aura Session Manager (SM) alarm be automatically cleared?

A. After 24 hours of the alarm's first report occurrence

B. When the alarm condition has been resolved

C. If an automatic alarm clearing rule has been specified

D. During the automatic nightly Avaya Aura System Manager (SMGR) alarm clearing
