300-610 Online Practice Questions and Answers

An engineer is designing a data center that uses FCIP. How is QoS configured in this environment?

A. A separate DSCP value and CoPP must be configured for all FCIP traffic and another for all of the FCIP in the data connection.

B. A separate DSCP value must be configured for all FCIP VSAN traffic.

C. A separate DSCP value and priority queuing must be configured for all FCIP traffic.

D. Two separate DSCP values must be configured, one of all of the FCIP frames in the control TCP connection and another for all of the FCIP frames in the data connection.

Which two statements describe Ethernet switching mode on Cisco UCS 6100 Series Fabric Interconnects? (Choose two.)

A. STP runs on the uplink ports of each VLAN, as defined by PVSTP+.

B. STP runs on the uplink ports of each VLAN, as defined by MSTP.

C. The STP parameter configuration is unsupported.

D. The STP parameter configuration is supported.

E. STP runs on the server ports.

An engineer is expanding an existing ISCSI environment and must choose an addressing scheme. When checking one of the devices, the engineer discovers this target device naming used {prefix}. 2019-01.com.acme.123:00. ftd0cb21.bcb389458389 Which addressing scheme was used in the environment?

A. Extended Unique identifier

B. Fibre Channel ID

C. ISCSI Qualified Name

D. Network Address Authority

An engineer must choose the World Wide Port Name for the Cisco UCS Fibre Channel virtual host bus adapter. Which identifier must be used?

A. naa.600a09840691712159764d

B. fe80::314e:4566:8702:bf3d

C. iqn.2021-08.com.acme:3xxx

D. 20:00:00:25:B5:97:c3:ac

A network consultant reviews the requirements for the Storage Area Network (SAN) design. The proposed solution must offer a very efficient port usage and eliminate the need for a separate physical layer of switches and their associated ISLs. The design is not expected to require future expansion.

Which SAN topology must be used to meet these requirements?

A. core-edge

B. collapsed-core

C. core-distribution-access

D. edge-core-edge

A engineer wants to eliminate the manual process of checking the system hardware and firmware against a specified hardware compatibility tool. The tool must be able to manage an extensive list of devices including cisco HyperFlex, MDS, and Nexus switches. The tool must manage hardware in multiple data centers so it should be deployed on public cloud infrastructure.

Which tool meets these requirements?

A. Cisco intersight

B. Cisco UCS director

C. Cisco data center network manager

D. Cisco tetration

A data center with over 4000 VLANs must be stretched to a disaster recovery site. The solution must support the migration of virtual machines to a disaster recovery site. To support the scalability of the solution, the internal fabric of the main site must be from the DCI network. The connecting network infrastructure uses a 10 Gbps link with PIM ASM supported, which will be replaced with a different overlay in the next 12 months. The solution must support head-end replication for

broadcast, unknown unicast, and multicast traffic. Which solution must be used to meet these requirements?

A. LISP

B. VXLAN Multi-Site

C. OTV

D. MPLS over GRE

An engineer must interconnect two data centers to support the dynamic virtual machine migration. The data centers are currently interconnected using an IPv4 network. However, the data plane encapsulation of the underlay network is expected to change next year. To meet the VM migration requirement, the solution must track MAC route changes, update all other remote devices simultaneously and prevent excessive MAC flapping with broadcast and unicast traffic loops. The company must also use networking equipment from different manufacturers to prevent vendor-locking. Which solution meets these requirements?

A. EoMPLS

B. OTV

C. EVPN

D. VXLAN

A network engineer needs to design a highly available data center to meet these requirements:

1.

ensure network resilience

2.

reduce network instability for Layer 3 gateway devices

3.

provide interoperability in multivendor environments

4.

support IPv4 and IPv6 address families

Which FHRP meets these requirements?

A. HSRP

B. HSRPv2

C. VRRPv3

D. VRRP

DRAG DROP

An engineer must deploy a SAN that meets these criteria:

The upstream director switch must be configured to minimize the number of issued domain IDs

The access switch must aggregate multiple locally connected ports not a single uplink that shares the same domain ID as the upstream switch.

Drag and drop the port types from the right onto the boxes on the left to create a SAN topology that meets these requirements Not all port types are used Port types are used more than once.

Select and Place:
