300-410 Online Practice Questions and Answers

Questions 4

Refer to the exhibit.

An IP SLA was configured on router R1 that allows the default route to be modified in the event that Fa0/0 loses reachability with the router R3 Fa0/0 interface. The route has changed to flow through router R2.

Which debug command is used to troubleshoot this issue?

A. debug ip flow

B. debug ip sla error

C. debug ip routing

D. debug ip packet

Buy Now
Questions 5

Refer to the exhibit.

A junior engineer updated a branch router configuration. Immediately after the change, the engineer receives calls from the help desk that branch personnel cannot reach any network destinations.

Which configuration restores service and continues to block 10.1.1.100/32?

A. route-map FILTER-IN deny 5

B. ip prefix-list 102 seq 15 permit 0.0.0.0/32 le 32

C. ip prefix-list 102 seq 5 permit 0.0.0.0/32 le 32

D. route-map FILTER-IN permit 20

Buy Now
Questions 6

How are MPLS Layer 3 VPN services deployed?

A. The RD and RT values must match under the VRF.

B. The import and export RT values under a VRF must always be the same.

C. The label switch path must be available between the local and remote PE routers.

D. The RD and RT values under a VRF must match on the remote PE router.

Buy Now
Questions 7

Refer to the exhibit.

AS111 is receiving its own routes from AS200 causing a loop in the network. Which configuration provides loop prevention?

A. router bgp 111 neighbor 195.1.1.1 as-override no neighbor 195.1.2.2 allowas-in

B. router bgp 111 neighbor 195.1.2.2 as-override no neighbor 195.1.1.1 allowas-in

C. router bgp 111 neighbor 195.1.1.1 as-override neighbor 195.1.2.2 as-override

D. router bgp 111 no neighbor 195.1.1.1 allowas-in no neighbor 195.1.2.2 allowas-in

Buy Now
Questions 8

Which command is the proper command for allowing RIP routing updates to be received on an interface while not allowing them to be sent out of the same interface?

A. Router(config)# passive-interface e0/0

B. Router(config-if)# passive-interface

C. Router(config-if)# interface passive

D. Router(config-router)# passive-interface e0/0

E. Router(config-router)# interface passive e0/0

Buy Now
Questions 9

You have a Frame Relay topology that is currently a hub and spoke using a single physical serial interface on the hub router with the default network type. OSPF is also running on the interface.

You execute the following command:

ip ospf network point-to-point

What would be the effect of executing this command on the serial interface of the hub router?

A. The hello interval for OSPF will change to 30 seconds

B. The dead interval for OSPF will change to 40 seconds

C. There will now be a DR election

D. The hub router must now be configured with a router ID

Buy Now
Questions 10

Refer to the exhibit.

A network engineer is provisioning end-to-end traffic service for two different enterprise networks with these requirements:

1.

The OSPF process must differ between customers on HQ and Branch office routers, and adjacencies should come up instantly.

2.

The enterprise networks are connected with overtapping networks between HQ and a Branch office.

Which configuration meets the requirements for a customer site?

A. ISP(config-if)#int f1/0 ISP(config-if)#ip vrf forwarding EA ISP(config-if)#description TO->EA2_Branch ISP(config-if)#ip add 172.16.200.2 255.255.255.0 ISP(config-if)#no shut

B. ISP(config-vrf)#int f0/0 ISP(config-if)#ip vrf forwarding EB ISP(config-if)#description TO->EB1_Branch ISP(config-if)#ip add 172.16.100.2 255.255.255.0 ISP(config-if)#no shut

C. ISP(config)#int f2/0 ISP(config-if)#ip vrf forwarding EA ISP(config-if)#description TO->EA1_HQ ISP(config-if)#ip address 172.16.100.2 255.255.255.0 ISP(config-if)#no shut

D. ISP(config-if)#int f3/0 ISP(config-if)#ip vrf forwarding EA ISP(config-if)#description TO->EA2_Branch ISP(config-if)#ip address 172.16.200.2 255.255.255.0 ISP(config-if)#no shut

Buy Now
Questions 11

Refer to the exhibit

SW100 cannot receive routes from R1 Which configuration resolves the issue?

A. Option A

B. Option B

C. Option C

D. Option C

Buy Now
Questions 12

Refer to the exhibit

A network administrator is troubleshooting to reduce the routing table of R4 and R5 to learn only the default route to communicate from Inter-Area and Intra-Area networks Which configuration resolves the issue?

A. Option A

B. Option B

C. Option C

D. Option D

Buy Now
Questions 13

Refer to the exhibit.

Jitter on the link between R101 and R201 was tested for voice traffic over port 16384 without the control communication on port 1967. Which command enables R201 to receive RTT for the configured IP SLA?

A. ip sla responder tcp-connect port 1967

B. ip sla responder udp-echo ipaddress 2.2.2.2 port 16384

C. ip sla responder udp-echo ipaddress 1.1.1.1 port 16384

D. ip sla responder auto-register 1.1.1.1

Buy Now
